PEKASOL® FG Refrigerant and heat transfer fluid

For the food processing industry Industry

Solvents & Plasticisers
  • PEKASOL® FG Refrigerant and heat transfer fluid

What is PEKASOL® FG?

Product description

PEKASOL® FG is a refrigeration and heat transfer fluid based on 1,2 propylene glycol for food processing and food manufacturing companies with NSF International approval. It is a colourless and odourless heat transfer fluid based on non-toxic and environmentally friendly monopropylene glycol, especially for the food industry and all applications where food quality is important.

The inhibitors reliably protect all materials commonly used in plant construction against sludge formation and corrosion. PEKASOL® FG is certified by NSF under HT1 in various ready-to-use dilutions and is offered exclusively in these concentrations. All ingredients are listed and approved by the FDA as food additives. Thus, in the event of an accident, the contamination of food products with the antifreeze is absolutely harmless and a health hazard in the event of unintentional consumption is excluded.

PEKASOL® FG is free of nitrite, amine, borate, silicate and nitrate.

About PEKASOL® FG

Dilution table PEKASOL® FG

With deionised water

Frost-resistant up to °C Vol.-% Density (20 °C) g/cm³ Refraction index NSF Registration no. HT1
-10 26 1,026 1.362 152492
-15 32 1,032 1.367 152493
-20 40 1,039 1.377 152494
-25 43 1,042 1.381 152495
-30 47 1,045 1.384 152496
-40 54 1,051 1.391 152497
-50 60 1,055 1.397 152498
< -50 1,060 1.431 152491

Packaging units PEKASOL® FG concentrate

Packaging Filling weight
30 litres can 30 kg
60 litres can 60 kg
220 litres drum 220 kg
1000 litres IBC 1,000 kg

Product data of PEKASOL® FG

Physical Characteristics PEKASOL® FG Concentrate

Density (at 20 °C) 1.06 g/cm3
Appearance clear, colorless liquid
Boiling point (concentrate) approx. 185 °C
pour point (concentrate) < -50 °C
pH value (at 20 °C) 8.5 - 10
Specific heat (at 20 °C) approx. 2.5 kJ/(kg-K)
Thermal conductivity (at 20 °C) approx. 0.22 W/(m-K)
Viscosity (at 20 °C) approx. 56 mPa-s
Electrical conductivity (at 20 °C) Dilution 1:2 approx. 4,000 μS/cm
Refractive index 1.431

Certification

The NSF has certified both the PEKASOL FG® concentrate and several difined dilutions. Only these dilutions mentioned in the dilution table correspond to the approval of the NSF.

The corresponding registration numbers (see dilution table) can be found on the NSF website at www.nsfwhitebook.org, quoting the company name or product name.

Instruction for use

One product for heating systems and cooling systems

PEKASOL® FG can be used both in heating systems and in cooling systems. Depending on the concentration, the operating temperatures range from -40 °C to +120 °C. All ready-to-fill dilutions supplied by us are diluted with deionised water (demineralised water). In order to ensure sufficient corrosion protection, the concentration should not fall below 26 % by volume. Only PEKASOL® FG must be used for refilling and concentrating, otherwise the NSF approval expires.PEKASOL® FG is suitable as an antifreeze additive for heating systems according to VDI 2035.

Learn more about the correct application of Pekasol FG® in our product brochure.

Further Products

The PEKASOL® FG System

Cleaning agent PEX FG

The cleaning additive concentrate PEX FG is used for cleaning and conditioning cooling systems which are to be filled with PEKASOL® FG. It is free of amines and nitrite and all ingredients are listed by the FDA as food additives.

Corrosion protection additive KOROSIN FG

The corrosion protection additive KOROSIN FG increases the corrosion protection proportion in a system operated with PEKASOL® FG.

Safety & Environment

Safety information

When handling PEKASOL® FG, the usual protective measures for handling chemicals must be observed. Further information and regulations can be found in the current EC safety data sheet.

Ecology and Toxicology

PEKASOL® FG is non-toxic and well biodegradable. PEKASOL® FG is certified by the NSF under HT1 and does not have to be labelled according to GHS. Water hazard class (WGK): 1, slightly water hazardous (according to VwVwS)

Shipping, storage and disposal

PEKASOL® FG is available in canisters, drums, IBCs and tankers. All containers are reusable packaging. Please empty completely before returning. Do not fill with other products!

PEKASOL® FG and all dilutions have good storage stability. Store in a dry place and avoid direct sunlight. PEKASOL® FG dilutions do not segregate even after prolonged storage. The applicable regulations must be observed during disposal.
